Replacing an Existing Thermostat

To replace an existing thermostat, first disconnect power at the circuit breaker. Remove the old thermostat by gently pulling it away from the wall. Disconnect the wires, noting their colors and positions for proper reconnection. Install the new Proselect thermostat by mounting it level and securing it with screws. Reconnect the wires to the corresponding terminals, ensuring no loose connections. Restore power and test the system to confirm proper operation. Always refer to the wiring diagram in the manual for compatibility and precise instructions.

Step-by-Step Installation Guide for the New Thermostat

Begin by turning off power to the HVAC system at the circuit breaker. Mount the new thermostat on a level surface, ensuring it is securely fastened with screws; Connect the wires to the appropriate terminals, referencing the wiring diagram for accuracy. Set the system switches to match your HVAC configuration. Restore power and test the thermostat by switching between modes (Heat, Cool, Off). Verify proper operation by checking airflow and temperature changes. If battery-powered, insert fresh AA batteries. Finally, program your desired settings or schedules, ensuring all features function as expected.

Wiring Diagrams and Compatibility

Refer to the wiring diagrams provided in the manual to ensure correct connections. The Proselect thermostat is compatible with 24V AC systems or can operate on AA batteries for backup power. Wiring diagrams detail connections for heating, cooling, and fan terminals. Ensure compatibility with your HVAC system, including heat pumps, by verifying the model specifications. Models like PSTSL11P52 and PSTSL21P52 support 2H/1C configurations. Always match wire colors to the correct terminals (e.g., R, W, Y, G, C). If unsure, consult the compatibility chart or contact customer support for assistance. Proper wiring ensures safe and efficient operation of your thermostat system.

Programming User Settings

Program your Proselect thermostat to customize temperature settings for weekdays and weekends. Set schedules for wake, leave, return, and sleep times to optimize comfort and energy savings easily.

Default Thermostat Settings

The Proselect thermostat comes with pre-set default settings designed for energy efficiency and comfort. These include standard temperature ranges for heating and cooling, as well as system mode preferences. Default settings are optimized for typical usage patterns, ensuring minimal energy consumption while maintaining desired comfort levels. Users can adjust these settings to match their specific needs, but the defaults provide a reliable starting point. The thermostat also retains these settings during power outages, ensuring consistent operation. Understanding and adjusting default settings is crucial for maximizing the thermostat’s performance and customizing its operation to your lifestyle.

Setting Temperature Differentials

The Proselect thermostat allows users to set temperature differentials, which determine the range between the current and set temperatures. This feature ensures the system starts heating or cooling in time to reach the desired temperature at the scheduled time. Accessible via the menu, temperature differentials are typically measured in degrees and can be adjusted to optimize comfort and energy efficiency. Properly setting this feature helps avoid unnecessary system cycles, reducing energy consumption while maintaining a consistent indoor climate. The default settings are designed for efficiency, but users can customize them based on personal preferences or specific environmental needs.

Programming Multiple Time Periods for Weekdays and Weekends

The Proselect thermostat enables users to program up to four time periods daily, with distinct settings for weekdays and weekends. This feature allows for tailored temperature control, enhancing comfort and energy savings. Preset schedules are recommended to minimize heating and cooling costs, but users can customize settings to suit their lifestyle. For example, set a lower temperature during sleep hours and a higher temperature when the house is unoccupied. The thermostat maintains the set temperature until the next scheduled period begins, ensuring consistent comfort. Adjustments can be made easily via the menu, offering flexibility for any schedule changes or preferences.

Operating Features

The Proselect thermostat offers advanced operating features, including temperature adjustment, system mode selection, and fan operation settings. These features ensure optimal comfort and energy efficiency year-round.

Temperature Adjustment and System Modes

The Proselect thermostat allows precise temperature adjustment and offers multiple system modes, including Heat, Cool, and Emergency Heat. Press the Mode button to cycle through available options. The thermostat displays the current system status, such as “Heat On” or “Cool On,” ensuring clear operation. Users can program up to four time periods daily, with distinct settings for weekdays and weekends. This feature helps reduce energy consumption while maintaining comfort. The screen illuminates for 45 seconds after changes when powered by a C wire, or 8 seconds on battery power, depending on installation. Adjusting schedules is intuitive, allowing users to optimize their settings for energy efficiency and convenience.

Fan Operation and Additional System Settings

The Proselect thermostat offers advanced fan operation settings, allowing users to control airflow independently of heating or cooling. Press the Mode button to cycle through system modes, including continuous fan operation for consistent air circulation. Additional settings enable customization of system behavior, such as enabling adaptive recovery for efficient temperature regulation. The thermostat integrates seamlessly with programmed schedules, ensuring optimal performance during set periods. Energy-saving features, like reducing heating/cooling expenses, are highlighted in the manual. These settings enhance comfort while maintaining energy efficiency, providing users with a tailored experience for their home environment.

Troubleshooting Common Issues

Common issues include blank displays, low battery warnings, and system mode problems. Check circuit breakers, ensure power switches are on, and replace batteries if necessary. Contact PROSELECT support at 1-800-221-3379 for further assistance.

Blank Display and Power-Related Problems

If your Proselect thermostat’s display is blank, ensure the power switch for your HVAC system is on and check the circuit breaker. For battery-powered models, replace batteries if the low battery warning appears. If using a C-wire, verify it’s connected properly. If the thermostat is battery-only, the screen may dim or turn off to conserve power. Press any button to wake the display. If issues persist, restart the thermostat or consult the manual. Contact PROSELECT support at 1-800-221-3379 for further assistance. Always ensure proper installation and power configuration to avoid display issues.

Low Battery Warning and Battery Replacement

The Proselect thermostat displays a low battery warning when power is critically low. When “BATT” and the battery icon appear, replace the AA alkaline batteries. For non-wired models, batteries are essential. To replace, gently press and release the thermostat face, then pull it away from the wall. Insert fresh batteries, ensuring correct polarity. If the thermostat is wired, batteries are optional for backup power. After replacement, the display should resume normal operation. If issues persist, contact PROSELECT support at 1-800-221-3379 for assistance. Always use genuine parts for optimal performance and warranty validity.

Advanced Features

The Proselect thermostat offers advanced features like Adaptive Intelligent Recovery, which learns your system’s needs to optimize heating/cooling efficiency. Temporary Program Overrides allow quick temperature adjustments without altering scheduled settings. These features enhance comfort and energy savings.

Adaptive Intelligent Recovery

The Proselect thermostat features Adaptive Intelligent Recovery, a smart technology that learns your heating or cooling system’s behavior to optimize performance. This advanced feature ensures your home reaches the desired temperature by the scheduled time, adjusting recovery times based on historical data. It minimizes energy waste by predicting how long it takes for your system to heat or cool your space effectively. By continuously adapting to your system’s performance, it enhances comfort and energy efficiency. This intelligent recovery system works seamlessly with your programmed schedules, delivering precise temperature control without manual adjustments.

Temporary Program Overrides

The Proselect thermostat allows for Temporary Program Overrides, enabling users to adjust the temperature without altering the permanent schedule. By pressing the appropriate button, you can set a temporary temperature that remains until the next scheduled period begins. This feature is ideal for occasional changes, ensuring comfort without disrupting your programmed settings. The thermostat will revert to its original schedule automatically, maintaining energy efficiency and convenience. This override capability enhances flexibility, allowing quick adjustments while preserving your preferred temperature plan. It’s a practical solution for temporary comfort needs without complicating your routine settings.

Maintenance and Support

Regular maintenance ensures optimal performance. Clean the thermostat display and check batteries. For support, contact Proselect via owatferguson.com or call 1-800-221-3379.
